Rotary Screw Air Compressor

ROTARY TYPE SCREW AIR COMPRESSOR
	CFM	M3/Min	CFM	M3/Min	CFM	M3/Min	CFM	M3/Min	NOISE	MOTOR			DIMENSION(MM)			WEIGHT	AIR CONNECTION
Model	@		@		@		@		dB(A)	POWER		RPM	Length	Width	Height	kg	Inches
Model	7 BAR/ 100 PSI		8 BAR/ 115 PSI		10 BAR/145 PSI		12.5 BAR/180 PSI		dB(A)	Kw	HP	RPM	Length	Width	Height	kg	Inches
UCT-RA-7	35	1	34	0.95	30	0.85	25	0.7	64	5.5	7.5	1440	850	700	1050	480	3/4″
UCT-RA-10	48	1.35	42	1.2	35	1	28	0.8	66	7.5	10	1440	850	700	1050	520	1″
UCT-RA-15	64	1.8	57	1.6	46	1.3	35	1	66	11	15	1460	1050	800	1100	650	1″
UCT-RA-20	88	2.5	81	2.3	71	2	60	1.7	68	15	20	1460	1050	800	1100	650	1″
UCT-RA-25	106	3	99	2.8	88	2.5	71	2	68	18.5	25	1470	1150	850	1250	770	1¼”
UCT-RA-30	134	3.8	120	3.4	104	3.1	95	2.7	70	22	30	1470	1150	850	1250	770	1¼”
UCT-RA-40	184	5.2	177	5	152	4.3	134	3.8	70	30	40	1470	1200	950	1450	1080	1½”
UCT-RA-50	230	6.5	215	6.1	194	5.5	173	4.9	72	37	50	1480	1200	950	1450	1080	1½”
UCT-RA-60	283	8	265	7.5	247	7	212	6	73	45	60	1480	1450	1100	1530	1420	2″
UCT-RA-75	371	10.5	346	9.8	304	8.6	268	7.6	73	55	75	1480	1450	1100	1530	1420	2″
UCT-RA-100	498	14.1	452	12.8	410	11.6	353	10	75	75	100	2970	2000	1250	1700	1950	2″
UCT-RA-125	565	16	530	15	480	13.6	431	12.2	75	90	125	2970	2000	1250	1700	2050	2″
UCT-RA-150	724	20.5	671	19	607	17.2	523	14.8	77	110	150	2980	2200	1600	1860	3000	2″
UCT-RA-175	851	24.1	809	22.9	724	20.5	593	16.8	77	132	175	2980	2700	1700	1800	3500	3″
UCT-RA-200	999	28.3	953	27	865	24.5	724	20.5	79	160	220	2980	2700	1700	1800	3800	3″
UCT-RA-300	1360	38.5	1264	35.8	1136	35.2	1006	28.5	79	200	270	2980	3000	1800	1800	4800	4″
UCT-RA-350	1547	43.8	1662	41.4	1335	37.8	1165	33	80	250	340	2980	3000	1800	1800	5000	4″
UCT-RA-400	1836	52	1695	48	1519	43	1377	39	80	315	430	2980	3000	1800	1800	6000	4″

All product, product specifications and data are subject to change without notice to improve reliability, function or design or otherwise
